Vi Characteristics Of Forward Biased Diode

A diode is a semiconductor device that allows current to flow in one direction while blocking it in the opposite direction. When a diode is forward biased, it conducts electricity, following specific Voltage-Current (VI) characteristics. Understanding these characteristics is essential for designing electronic circuits, especially in rectifiers, amplifiers, and switching applications.

This topic explains the VI characteristics of a forward biased diode, how it behaves under different voltage conditions, and its significance in practical applications.

What Is a Forward Biased Diode?

A diode is forward biased when the positive terminal of the voltage source is connected to the anode and the negative terminal is connected to the cathode. In this condition, the diode allows current to flow freely.

Key Features of a Forward Biased Diode

  • The applied voltage reduces the depletion region, making it easier for current to flow.
  • A small threshold voltage must be exceeded before significant conduction begins.
  • The diode exhibits a nonlinear VI characteristic, meaning its resistance changes with voltage.

VI Characteristics of a Forward Biased Diode

1. The Threshold Voltage (Cut-in Voltage)

A diode does not conduct immediately when a small voltage is applied. Instead, a minimum voltage, known as the threshold voltage (V₀) or cut-in voltage, must be reached.

  • Silicon diodes: The cut-in voltage is about 0.7V.
  • Germanium diodes: The cut-in voltage is about 0.3V.

Until this voltage is reached, the diode remains in a non-conducting state, allowing only a negligible leakage current.

2. The Exponential Current Increase

Once the applied voltage exceeds the cut-in voltage, the current increases exponentially rather than linearly. This behavior is described by the Shockley diode equation:

I = I_s left(e^{frac{V}{nV_T}} – 1right)

Where:

  • I = Diode current
  • I_s = Reverse saturation current (a very small leakage current)
  • V = Applied voltage
  • V_T = Thermal voltage (~25mV at room temperature)
  • n = Ideality factor (typically between 1 and 2)

This equation shows that a small increase in voltage leads to a large increase in current.

3. The Linear Region (Ohmic Behavior at High Currents)

As the forward voltage increases further, the diode enters a region where its internal resistance becomes dominant. Here, the VI curve appears almost linear, and the diode behaves like a small resistor with very low resistance.

4. Power Dissipation and Temperature Effects

  • When a diode conducts, it dissipates power in the form of heat, given by:

    P = V times I
  • Excessive heat can damage the diode, so heat sinks or cooling mechanisms are often used in high-power applications.

  • Temperature increase reduces the cut-in voltage, making the diode conduct at lower voltages.

Graphical Representation of VI Characteristics

A typical VI characteristic curve of a forward biased diode includes:

  1. Non-conducting region: No significant current flows until the cut-in voltage is reached.
  2. Rapid current increase: Once past the threshold, the current rises exponentially.
  3. Linear region: At high voltages, the diode acts almost like a resistor.

Factors Affecting the VI Characteristics

1. Type of Semiconductor Material

  • Silicon diodes require higher voltage to conduct but have lower leakage current.
  • Germanium diodes conduct at lower voltages but are more temperature-sensitive.

2. Temperature Dependence

  • As temperature increases, the threshold voltage decreases.
  • Higher temperatures cause an increase in reverse leakage current.

3. Manufacturing Variations

  • Different diodes (e.g., Schottky diodes, Zener diodes) have different VI characteristics based on their construction.

Applications of Forward Biased Diodes

1. Rectifiers in Power Supplies

  • Converts AC to DC in power adapters and chargers.

2. LED (Light Emitting Diodes)

  • LEDs operate under forward bias and emit light when current flows through them.

3. Clipping and Clamping Circuits

  • Used in signal processing to limit voltage levels.

4. Voltage Regulation

  • Zener diodes in forward bias stabilize voltage in circuits.

5. Switching Circuits

  • Used in logic gates and microprocessor circuits.

The VI characteristics of a forward biased diode describe how the diode transitions from a non-conducting state to full conduction. The threshold voltage, exponential current increase, and temperature dependence play a crucial role in diode performance. Understanding these characteristics is essential for designing efficient electronic circuits, whether for power conversion, signal processing, or LED applications.
